Automatic Loading Stretcher NF-L1

Technical features:

Low position stretcher, suitable for low height board ambulance

The backrest can be adjusted from 0 - 65 deg by gas spring

Swing-down side rails to protect patient when transfer

The bottom space of the stretcher is designed for storage of scoop stretcher

The stretcher can be locked by the fixing device when it is in the ambulance

It is made of high-strength aluminum alloy

φ125mm castors, diagonal brakes, swivel front castors and non-swivel rear castors

Mainly used for ambulance, hospitals, emergency centers

Suitable for the ambulance: the wheel hub height is less than 29cm

Accessories:

Waterproof seamless welding PVC mattress(5cm thickness foam)

3pcs belts for chest, hip and knee

Fixing device L02

Optional:

IV pole I01

Pillow

Model Unfolded size(L*W*H) Max angle of
the backrest
Distance between
front and rear wheel
N.W Load bearing Packing
Quantity Size(L*W*H) G.W
NF-L1 190*55*44cm 65° 120cm 25kg 180kg 1 195*58*34cm 32kg
