Ambulance Stretcher NF-A1-2

Technical featuresú║

It has a separable stretcher with the main stretcher frame which could be removed from trolley and used as a separate stretcher, easy locking/unlocking system to lock the separable stretcher into the trolley

Two sets loading wheels to fit different height of ambulance board

The backrest can be adjusted from 0 - 65 deg by gas spring

Swing-down side rails to protect patient when transfer

The mechanical legs are controlled by the handles in both sides, there is a safety lever to control front and hind legs to fold while loading and prevent collapse while standing

Only one person can slide the stretcher on to the ambulance

The stretcher can be locked by the fixing device when it is in the ambulance

It is made of high-strength aluminum alloy.

φ150mm wide rubber castors, two with brakes

Mainly used for ambulance, hospitals, emergency centers

Accessories:

Waterproof seamless welding PVC mattress(5cm thickness foam)

3pcs belts for chest, hip and knee

Fixing device L01-1

Optional:

IV pole I01

Pillow

Oxygen holder H01 or H02

Model   High position   Low position Maximum angle of the back   N.W Load Bearing Packing
Quantity Size(L*W*H) G.W
NF-A1-2 195×55×85cm 195×55×25cm 65° 43kg 180kg 1 204×62×30cm 50kg
